Brono LED Wall Pack Series

The Brono wall Pack is the ideal solution for commercial and residential applications. This classic fixture is a great option to uniformly illuminate warehouse, factory and stadiums.

Use:
industrial
commercial

Application:
Exterior building,Tunnel,Walkway,Wall,Entryway

Description

The Brono Wall Pack is the ideal solution for commercial and residential applications. This classic fixture is a great option to uniformly illuminate warehouse, factory and stadiums. Main structural component for the lamp body is ADC12 die-cast aluminum, with advantages of shock and corrosion resistance. This wallpack is also made with high temperature resistant silicone seals to eliminate atomization.

SPEC SHEET

Variations SKU NUMBERDelivered Lumens (lm)Wattage (W)Efficacy (lm/W)Input VoltageSize (cm)Weight (KG)
BRO-WP-0040520040130100-277V36x23x193.5
BRO-WP-0060780060130100-277V36x23x193.5
BRO-WP-00801040080130100-277V36x23x194.0
BRO-WP-010013000100130100-277V36x23x194.0

BRO-WP Specifications:

  • Power: 40W / 60W / 100W / 120W
  • Size: 360x232x192mm
  • Lumen: 4,800lm / 7,200lm / 12,000m / 14,400lm
  • Beam Angle: 120
  • CCT: 2700 / 3000 / 4000 / 5000 / >6000k
  • Voltage: AC100-277V
  • Power Factor: >0.95
  • CRI: >83
  • Net Weight: 3.28kg / 4.12kg

SPEC SHEET DOWNLOAD



IES

IES Download

Installation guide

Installation guide Download
