SPEC SHEET

SLD-HB-XXXX Specifications

• Listing: CSA US-Canada Certified for Wet Locations. BC Hydro e.Catalog Listed.
• LED: Industry-leading Cree ceramic LEDs. Developed for superior lumen and thermal reliability, high light intensity, and easy optical control in a compact chip size.
• Optics: Clear impact-resistant polycarbonate lens. Surface-mounted optics for precise light control, high optical efficiency.
• Optional Beam Angles: 10°, 25°, 60°, 90°, 120°, 131° s: 10°, 25°, 60°, 90°, 120°, 131°, Type II, Type III
• Available CRI: 70, 80, 90
• Colour Temperature (CCT): 2700-6500 K
• Standard Warranty: 5 years
• Reported (and Projected) TM-21-11 LED Lumen Maintenance:
  • L90 (90% light output) > 145,000 hours (Projected 150,000 hours)
  • L70 (70% light output) > 145,000 hours (Projected 457,000 hours)
• Input Voltage: 120-277/347VAC (50/60 Hz)
• Operating Temperature: -40˚C to +50̊C
• Construction: High-quality steel bell with colored powder coated finish for corrosion protection and aesthetic. IP67 LED engine utilizes a robust extruded aluminum heatsink with PC lens cover. All electrical components rated minimum IP67.
• Standard Dimensions: Dia. 50 cm × Height 26 cm [Ø19.8 in × 10.1 in]
• Standard Weight: 8.55 kg - 9.77 kg [18.8 lb. - 21.5 lb.]
• Installation: Single-point suspension via attached eyebolt.
• Features: 0/1-10V dimming, multifunctional occupancy sensor, surge protection, housing color.

CONFIGURATION

• Multifunctional Occupancy Sensor
• 0/1-10V Dimming
• Additional Surge Protection
• Cosmetic Options
• Single-point Suspension (Chain)
