SPEC SHEET

EAG-EX-XXXX Specification

• Certifications: UL Listing. US-Canada.
• UL1598—LED Luminaire Certification
• UL1598A Marine Outside Type
• UL924—Emergency Lighting Equipment
• Class III
• UL844—Hazardous Location Certification—
• Class I Division 2 Groups ABCD, Class II Division 2 Groups FG, Class III
• Class I Zone 2 Group IIC, Class II Zone 21 Group IIIC
• T3 Temperature ratings
• IK08 Impact Rating with glass cover, IK10 Impact Rating with wire guard
• IP66/67 Ingress Rating, 1000-hr Salt Spray Rated
• DLC Listed
• Colour Rendering Index: Ra > 70
• Color Temperature (CCT): 2700K, 4000K, 5000K, 6000K, 7000K
• Standard Operating Temperature: -40°C to +60°C (T3 Temp Code)
• Electrical: Input: 120-277 Vac, 50/60 Hz, Power Factor: >0.95, THD: < 20%, Surge: 4 kV
• Construction: Copper-free aluminum with stainless steel hardware. Optical construction utilizes flat or convex lenses. Side Opening Cover models allow for plug or cable entry. 3/4-in NPT and 1/2-in NPT included.
• LED: High-efficiency surface mount LED technology. 140lm/W delivered lumen efficiency.
• Lens & Optics: Flat glass or convex polycarbonate lens cover (clear or diffuse available) Standard 120° FHWM beam optics.
• Installation: Wall, Ceiling, Suspension, Pendant or Pole mount
• Feature: 0-10V Dimming. Emergency Battery Backup Option.
• Reported TM-21-11 LED Lumen Maintenance: L70 (70% light output) > 72,000 hours
• Warranty: 5 years for Fixture, 3 years for Battery Backup
